Technische specificaties
- Tube: SRO 33100 ROT380 (for CS)
-
Tube: SRO 33100 ROT380 (for CS) Anode heat storage capacity - 300 kHU (200kJ)
focal spot - 0.6 /1.2
Maximum voltage - 150 kV
-
- Ceiling Suspension
-
Ceiling Suspension Collimator - Motorized, automatic
Ceiling height at SID 110 cm (44") - 2.83 m to 3.21 m (8'8.3" - 10'5.9")
Type - Four-part telescopic column
-
- Geometry
-
Geometry Source to Image Distance (SID) - 113 cm – 183 cm (44’’ to 72’’)
-
- Wireless detector: SkyPlate Large
-
Wireless detector: SkyPlate Large Active area - 34.48 cm x 42.12 cm (13.6" x 16.6")
Type - Digital Csl (Cesium Iodide) flat detector
Detector size - 35 cm x 43 cm (14" x 17")
Image matrix size - 2330 x 2846 pixel
-
- Wireless detector: SkyPlate Small
-
Wireless detector: SkyPlate Small Detector size - 24 cm x 30 cm (app. 10" x 12")
Active area - 22.2 cm x 28.4 cm (8.7" x 11.2")
Image matrix size - 1500 x 1920 pixel
Type - Digital Csl (Cesium Iodide) flat detector
-
- Tube: SRO 33100 ROT380
-
Tube: SRO 33100 ROT380 focal spot - 0.6 /1.6
Anode heat storage capacity - 300 kHU (200kJ)
Maximum voltage - 150 kV
-
- Tube: SRM 0608 ROT GS 505
-
Tube: SRM 0608 ROT GS 505 Maximum voltage - 125 kV (110 kV in GCF)
Anode heat storage capacity - 800 kHU (593kJ)
focal spot - 0.6 /0.8
-
- Dynamic Flat Detector
-
Dynamic Flat Detector Acquisition mode pulsed fluoroscopy - Up to 20 per second
Image matrix size - 2,874 pixel x 2,840 pixel
Detector Size - 43 cm x 43 cm (17"x17")
Acquisition mode continious fluoroscopy - Up to 30 frames per second
Pixel size - 148 µm
-
- Generator
-
Generator Tube voltage flouroscopy - 40 - 125 kV
Tube voltage exposure - 40 - 150 kV
Power - 65 kW, 80kW optional
Fluoroscopy techniques - Pulsed fluoroscopy (PF), in-pulse controlled
- Grid-controlled fluoroscopy (GCF), in-pulse controlled
Exposure techniques - Manual: kV-mAs or kV-mA-s
- Automatic Exposure Control (AEC) - Intelligent Exporuse (IQX), In-Pulse controlled
- Automatic kV reduction techniques
-
- Geometry
-
Geometry Maximum patient weight - 284 kg (626 lbs) without limitations
Tube column movement range - 160 cm (63")
Table tilt angle - -90°/+90°
Motorized compressor - 3 kg - 15 kg (6.6 lbs - 33.1 lbs) compression force
Table height - 62 cm - 142 cm (24.4"-59.9")
-
- Digital vertical stand
-
Digital vertical stand Motorized tilting - Optional, -20° to +90°
Detector Size - SkyPlate detector
Vertical travel - 30 cm - 180 cm (11.8" - 5'11")
-
- Tube: SRO 33100 ROT380 (for CS)
-
Tube: SRO 33100 ROT380 (for CS) Anode heat storage capacity - 300 kHU (200kJ)
focal spot - 0.6 /1.2
-
- Ceiling Suspension
-
Ceiling Suspension Collimator - Motorized, automatic
Ceiling height at SID 110 cm (44") - 2.83 m to 3.21 m (8'8.3" - 10'5.9")
-
- Tube: SRO 33100 ROT380 (for CS)
-
Tube: SRO 33100 ROT380 (for CS) Anode heat storage capacity - 300 kHU (200kJ)
focal spot - 0.6 /1.2
Maximum voltage - 150 kV
-
- Ceiling Suspension
-
Ceiling Suspension Collimator - Motorized, automatic
Ceiling height at SID 110 cm (44") - 2.83 m to 3.21 m (8'8.3" - 10'5.9")
Type - Four-part telescopic column
-
- Geometry
-
Geometry Source to Image Distance (SID) - 113 cm – 183 cm (44’’ to 72’’)
-
- Wireless detector: SkyPlate Large
-
Wireless detector: SkyPlate Large Active area - 34.48 cm x 42.12 cm (13.6" x 16.6")
Type - Digital Csl (Cesium Iodide) flat detector
Detector size - 35 cm x 43 cm (14" x 17")
Image matrix size - 2330 x 2846 pixel
-
- Wireless detector: SkyPlate Small
-
Wireless detector: SkyPlate Small Detector size - 24 cm x 30 cm (app. 10" x 12")
Active area - 22.2 cm x 28.4 cm (8.7" x 11.2")
Image matrix size - 1500 x 1920 pixel
Type - Digital Csl (Cesium Iodide) flat detector
-
- Tube: SRO 33100 ROT380
-
Tube: SRO 33100 ROT380 focal spot - 0.6 /1.6
Anode heat storage capacity - 300 kHU (200kJ)
Maximum voltage - 150 kV
-
- Tube: SRM 0608 ROT GS 505
-
Tube: SRM 0608 ROT GS 505 Maximum voltage - 125 kV (110 kV in GCF)
Anode heat storage capacity - 800 kHU (593kJ)
focal spot - 0.6 /0.8
-
- Dynamic Flat Detector
-
Dynamic Flat Detector Acquisition mode pulsed fluoroscopy - Up to 20 per second
Image matrix size - 2,874 pixel x 2,840 pixel
Detector Size - 43 cm x 43 cm (17"x17")
Acquisition mode continious fluoroscopy - Up to 30 frames per second
Pixel size - 148 µm
-
- Generator
-
Generator Tube voltage flouroscopy - 40 - 125 kV
Tube voltage exposure - 40 - 150 kV
Power - 65 kW, 80kW optional
Fluoroscopy techniques - Pulsed fluoroscopy (PF), in-pulse controlled
- Grid-controlled fluoroscopy (GCF), in-pulse controlled
Exposure techniques - Manual: kV-mAs or kV-mA-s
- Automatic Exposure Control (AEC) - Intelligent Exporuse (IQX), In-Pulse controlled
- Automatic kV reduction techniques
-
- Geometry
-
Geometry Maximum patient weight - 284 kg (626 lbs) without limitations
Tube column movement range - 160 cm (63")
Table tilt angle - -90°/+90°
Motorized compressor - 3 kg - 15 kg (6.6 lbs - 33.1 lbs) compression force
Table height - 62 cm - 142 cm (24.4"-59.9")
-
- Digital vertical stand
-
Digital vertical stand Motorized tilting - Optional, -20° to +90°
Detector Size - SkyPlate detector
Vertical travel - 30 cm - 180 cm (11.8" - 5'11")
-
